Type 2 Diabetes mellitus is a disorder of carbohydrate metabolism which is characterized by a combination of peripheral insulin resistance and impaired insulin secretory capacity of pancreatic beta cell. In due course of time when it is unable to maintain sufficient hyper-insulinemic response, overt diabetes ensues. Modern synthetic medicines have several side effects compared to herbal drugs, due to which the popularity of traditional and complimentary medicines has increased^[1].

  The anti-hyperglycemic activity of Eugenia jambolana (Botanical name- Syzgium cumini) from its seeds, fruit pulp, bark and roots has been well established^[2-5]. It has also known to have several anti diabetic compounds such as ferulic acid, cuminoside, α-hydroxy succinamic acid, stigma sterol, β-sitosterol, lupeol, ellagic acid, gallic acid, quercetin and kempferol^[6]. Attenuation of renal dysfunction by anti-hyperglycemic compound isolated from fruit pulp of Eugenia jambolana in Streptozotocin-induced diabetic rats has also been reported^[7]. The fruit extract (250 mg/kg) lowered glucose in overnight fasted streptozotocin induced diabetic rats; the treatment increased glycogen content in liver, induced degranulation in β-cells. The fruit may stimulate insulin secretion. The water extract of the fruit pulp also showed anti-hyperglycemic activity in normal and alloxan-induced diabetic rats^[8].

  Sharma et al has already isolated the active antihyperglycemic compound known as alpha hydroxy succinamic acid (FIIc) (US Patent number 6,426,826 dated 6^th August 2002; Indian Product Patent number. 2,30,753 February 2009) from the fruit pulp of Eugenia jambolana^[8].

  Incretin hormones such as GLP 1 and GIP have shown to control post prandial glucagon release, delay gastric emptying and increase satiety^[9,10]. It has also been reported to stimulate insulin secretion^[11,12], stimulate beta cells proliferation and differentiation^[13,14]. However, GLP 1 has a very short half-life. It is rapidly degraded inside our body by the enzyme Dipeptidyl Peptidase 4 (DPP-4). Therapeutic agents that can block the DPP-4 enzyme (DPP-4 inhibitors) can increase the endogenous GLP-1 level and thus enhances the incretin action. Dipeptidyl Peptidase inhibitors, which act via enhancing the incretins represents another new therapeutic approach for the treatment of type 2 diabetes.

  Glucose uptake in peripheral tissues is also stimulated by Insulin receptor tyrosine kinase and under pathologic conditions may result in a range of clinical manifestations including diabetes^[15,16]. In a recent study it was shown that when non-obese diabetic mouse treated with tyrosine kinase inhibitors showed improved glycemic control and increased insulin sensitivity^[17,18]. Hence, the development of tyrosine kinase inhibitors offers increasing opportunities for the treatment of various diseases including diabetes.

  The present study was therefore planned to evaluate the effect of purified active principle (FIIc) on Streptozotocin-Nicotinamide induced diabetic rats and to ascertain its mechanism of action by evaluating its effect on DPP-4 levels and tyrosine kinase activity.

Materials and Methods

Isolation and purification of active anti-hyperglycemic compound (FIIc)
Preparation of crude aqueous extract: Fresh fruit pulp of Eugenia jambolana was grinded in a mixer grinder with distilled water (500 mL). After filtration through muslin cloth, the filtrate was centrifuged at 10,000 rpm at 4°C and then lyophilized to store it for a longer duration. The yield of lyophilized water extract was about 10 g from 650 g of fruit pulp, which was obtained from 1 kg fruits of E. jambolana.

  Ion exchange chromatography was carried out for the isolation and purification of active compound (FIIc) using diethyl amino ethyl cellulose- 52 (DEAE-52) as the stationary phase. Fractions were then eluted with 0.1 M phosphate buffer (pH 6.0). A total of four fractions (FI to FIV) were obtained out of which FII has the significant high anti-hyperglycemic activity among the four fractions. FII was again subjected to Ion exchange chromatography and active compound (FIIc) was obtained. The US and Indian patents have already been granted^[8].

Chemical characterization of active compound (FIIc): Homogeneity of FIIc was confirmed by HPL-C which gave a single peak after employing it on chromolith column (chromolith performance HPL-C column RP-18e 100 – 4.6 mm). FIIc was eluted with mobile phase (Water : Methanol : Acetonitrile :: 70 : 15 : 15) and monitored by PDA detector at wavelength 220 nm (Instrument Shimadzu HPL-C model SPD-M20A). A single peak was observed in chromatogram, suggesting that FIIc was almost homogenous as demonstrated in previous studies done by Sharma et al^[8].

Experimental animals: Male Wistar albino rats (weighing 220 - 250 grams) were procured from Central Animal House of University College of Medical Sciences (UCMS), University of Delhi, India. The animals were housed in standard conditions of temperature (22 ± 2°C) and at 12 hour light-dark cycle. The rats were fed with commercial diet (Hindustan liver Ltd., Mumbai) and water ad libitum. The experimental protocol was approved by the Institutional Animal Ethical Committee (IAEC), UCMS, Delhi, India (UCMS/IAEC/26 granted on 30^th December 2009).

Induction of diabetes: To induce diabetes, a freshly prepared solution of streptozotocin (45 mg/kg of body weight in 0.1 M citrate buffer, pH 4.5) was injected intraperitoneally to overnight fasted rats. Nicotinamide at a dose of 230 mg/kg body weight was given 15 minutes prior to STZ injection for the development of stable type 2 diabetes mellitus^[19]. After 48 hours of STZ administration, fasting blood glucose (FBG) levels were measured.

Study design: Male Wistar rats were taken for the present study and divided into following groups (6 rats each group).
Group A: Healthy control (normal saline)
Group B: Diabetic control (normal saline)
Group C: Diabetic treated with FIIc (20 mg/kg of body weight)
Group D: Diabetic treated with Pioglitazone (20 mg/kg of body weight)

  Animals in group A and B were given standard chow diet. Purified active compound (FIIc) was given orally to group C at a dose of 20 mg/kg of body weight day for 4 weeks, which is the effective dose of FIIc standardized in previous studies done by Sharma et al^[8]. Pioglitazone was given as a standard drug orally at a dose of 20 mg/kg of body weight /day for 4 weeks to group D. An equal volume of vehicle was given to healthy control group A and diabetic untreated group B.

Glycemic parameters and hormonal assays: Blood was drawn from retro orbital plexus by using micro-capillary technique from all overnight fasted animals on day 1 and afterwards at week 4 of the study. Whole blood was drawn for the estimation of Glycosylated hemoglobin and plasma was separated from blood for the estimation of Glucose. Serum was separated for the estimation of lipids, Insulin and Dipeptidyl Peptidase-4. These samples were carefully processed and stored in -80°C deep freezer. These parameters were measured using commercially available kits: plasma glucose (Fortress diagnostics, United Kingdom), HbA1c (Fortress diagnostics, United Kingdom), total serum cholesterol (Fortress diagnostics, United Kingdom), serum triglycerides (Fortress diagnostics, United Kingdom), HDL-C (Fortress diagnostics, United Kingdom), Insulin (Mercodia rat ELISA kit, Sweden), tyrosine kinase (Bio medical Assay rat ELISA kit, China) and DPP-4 (Bioassay technology laboratory rat ELISA kit, China) respectively. Each time quality control sera (Bio-Rad, USA) were run along with the samples. Results of the unknown sample and quality control sera were reproducible.

Insulin Receptor (IR)-binding assay: After 4 weeks of treatment rats were sacrificed and their organs including liver and adipose tissues were dissected for the estimation of protein tyrosine kinase activity. These tissues were collected and solubilized by lysis buffer. IR-binding assay was performed using Rayto 2100c microplate ELISA reader (Rayto, China). The amount of phosphorylated IR was quantified by sandwich enzyme-linked immunosorbent assay (ELISA). The absorbance was measured at 450 nm through ELISA plate reader.

Statistical analysis: Two way ANOVA was applied for the comparison of parameters between the groups followed by Tukey’s test. Pearson’s coefficient of correlation was calculated for all the 3 groups together and separately for all the above mentioned parameters. Difference was assumed to be significant at the level of p < 0.05.

Results

Effect of FIIc on glycemic index
  In the present study a significant improvement was observed in body weight, glycemic and lipid profile in FIIc treated rats at week 4 of the study compared to diabetic controls. Serum insulin and HDL-C were found to be significantly increased in FIIc treated rats at week 4 of the study compared to diabetic controls (Table 1).

Table 1: Showing body weight, glycemic, lipid and hormonal profile at week 0 and at week 4 after treatment with FIIc and Pioglitazone.

Values are mean ± S.D. (n = 6). (p < 0.001)
a = group A vs. Group B, b = Group A vs. Group C, c = Group A vs. Group D, d = Group B vs. Group C, e = Group B vs. Group D.

Effect of FIIc on tyrosine kinase activity
  After treatment with active compound (FIIc), we have observed 55.5 % and 49.22 % increase in tyrosine kinase activity in liver and adipose tissues respectively compared to the diabetic controls rats at week 4 of the study. Group D rats treated with Pioglitazone also demonstrated 58.94 % and 62.7 % increase in tyrosine kinase activity in liver and adipose tissues respectively compared to the diabetic controls (Table 1).

Effect of FIIc on serum DPP 4 levels
  As indicated from table 1, the baseline values of serum DPP-4 levels were found to be similar between the various study groups. But on week 4 of the study we observed a (p < 0.001) significant decrease in serum DPP-4 levels in group C compared to group B rats. FIIc treated rats demonstrated an 18.56 % decrease in serum DPP-4 levels at week 4 of the study compared to baseline levels while no decrease was observed in DPP-4 levels in Pioglitazone treated group D rats.

Discussion

  In the present study, we studied the effect of HPL-C purified active compound FIIc isolated from the fruit pulp of Eugenia jambolana in animal model of diabetes on various glycemic, lipid, hormonal parameters and the activity of protein tyrosine kinase after 4 weeks of treatment.

  Due to the partial destruction of pancreatic beta cells, we observed decreased serum Insulin levels and tyrosine kinase levels in diabetic control rats compared to healthy controls (Table 1). After treatment with active compound FIIc for 4 weeks we observed a significant increase in serum insulin levels and activity of protein tyrosine kinase in liver and adipose tissue homogenates of FIIc treated rats compared to diabetic controls (Table 1). Reduced tyrosine kinase activity in diabetes has been reported in previous studies^[15,16]. This decrease in tyrosine kinase activity is may be due to hyperglycemia which activates protein kinase C leading to production of insulin receptor with phosphorylated serine residue which in turn may prevent subsequent beta subunit tyrosine phosphorylation^[20,21]. Reduced insulin level also leads to decreased binding of insulin to its tyrosine kinase receptors which ultimately caused increased blood glucose levels. Insulin stimulates the increased uptake of glucose through increased binding of insulin to its tyrosine kinase receptors. Insulin also causes increase in activity of protein tyrosine kinase through phosphorylation of beta subunit and decrease in protein kinase C activity. Animal studies have also reported beneficial effects of Cinnamon extract, a traditional herb on serum insulin levels and tyrosine phosphorylation^[22]. After treatment with Cinnamon extract, the author has reported a significant increase in glucose infusion rate at 3 mU/kg per min Insulin infusion compared with healthy controls. It was suggested that the cinnamon extract potentiated increased glucose uptake via enhancing the insulin signaling pathway^[22].

  Studies have also reported that treatment with tyrosine kinase inhibitors leads to reduction in insulin requirements and improved glycemic control in diabetes^[23-25]. Lo et al. has demonstrated in Taiwanese population the beneficial effects of traditional Chinese medicinal formula in type 2 diabetes^[26]. It has been reported to ameliorates glycemic index and impaired insulin secretion via phosphatidylinositide 3-kinase (PI3K)/Akt pathway in diabetic animals^[26]. He proposed that the herbal drug CYSKT increased the amount of phosphorylated IR and stimulated the translocation of GLUT-4 to cell membrane and suggested that CYSKT might bind to IR, which in turn activate the phosphorylation of IR, and stimulate the down-stream signaling pathway. In his previous study, it has also been reported that a protein component from Momordica charantia binds to IR, activates the insulin signaling pathway, and lowers the blood glucose levels in diabetic mice^[27]. Similar findings have also been reported by Zhao et al^[28]. Our results are in consonance with previous studies which also shows that the herbal treatment improves tyrosine kinase activity leading to improved glycemic profile.

  In our study we have also observed a significant decrease in serum DPP-4 levels in FIIc treated rats compared to diabetic controls. Studies have reported dysregulated serum DPP-4 levels during diabetic conditions^[29]. DPP-4 inhibition by active compound FIIc resulted in increased incretin levels which in turn stimulated beta cells leading to increased insulin levels as reflected by our results at week 4 of the study (table 1). Histopathology of pancreases also showed increased Beta cell islets in FIIc treated (Figure 1) rats compared to diabetic controls (Figure 2). Our results are also supported by previous studies as GLP-1 has been reported to maintain glucose homeostasis and increase insulin secretion in glucose dependent manner^[30,31]. Administration of, GLP-1 and its analogs have also shown beneficial glucose lowering effects in diabetic subjects^[32] and in animal model of diabetes^[33,34]. Studies have also reported that these agents were known to have beneficial effects on islets neogenesis, beta cell survival and differentiation^[35,36]. Previous studies have also reported that elevated levels of circulating GLP-1 and GIP were observed in DPP 4 deficient mice which are resistant to STZ-induced beta cell destruction^[37,38]. Also GLP-1 treatment has been reported to prevent streptozotocin induced beta cell apoptosis^[39,40]. Studies have also reported that mice lacking both GLP-1 and GIP receptors clearly demonstrate that these incretins are acutely responsible for DPP 4 inhibition and glycemic controls^[41]. A study by Zhang et al. reported that alogliptin restored the β-cell mass and islet morphology, and increased insulin secretion in their diabetic mouse model induced by STZ treatment^[42]. Similar results were reported by Ahren and HughesA^[43].

  Increased serum insulin levels is also responsible for increased uptake of triglycerides from the blood into the muscles and adipose tissues, decreased rate of lipolysis in adipose tissues therefore lowers plasma fatty acid levels^[44]. Hence we observed increased body weight and improved glycemic profile in FIIc treated rats compared to diabetic controls (Table 1). Rats treated with Pioglitazone also demonstrated similar results as it is known to have insulin sensitizing properties resulting in improved glycemic index and lipid profile.

  Hence we conclude that purified active compound (FIIc) isolated from the fruit pulp of Eugenia jambolana has significant effect on glycemic control, serum lipid profile and insulin sensitivity. It also significantly decreased serum DPP-4 levels and improves the altered levels of protein tyrosine kinase which is involved in establishing a smooth insulin signaling mechanism.

Figure 1: Showing regenerated Islets of pancreatic beta cell mass after treatment with active compound FIIc in group C rats at week 4 of the study.

Figure 2: Showing Streptozotocin-NAD induced degenerated Islets of pancreatic beta cell mass in group B rats at week 4 of the study.

Conclusion

  Thus FIIc significantly reduces hyperglycemia, hyperlipidemia via inhibiting serum DPP-4 levels and improves serum insulin and tyrosine kinase activity, and it may prove potential herbal compound for the management of type 2 diabetes.

Acknowledgement:
  The authors acknowledge Indian Council of Medical Research, New Delhi for their financial support.

Conflict of Interest:
  The authors declare that they have no conflicting interests.
